4" Low Voltage Brass Down Light - 12V - LED Ready Fixture with RGB+CCT MR16 Bulb - Optional RF Remote
Part Number:
WSR-LRR-RGBMR16-V-x
Manufacturer Part Number:

calcActive())">
Starting at
$68.95
ea.
Starting at
Was
Features
- Adjustable modes, colors, tunable whites, speed, and brightness
- Control bulb with RF Remote or Tuya Smart App
- Constructed with a silicone o-ring to prevent water intrusion
- Solid brass housing and a durable glass lens
- Lifetime Warranty
Overview
The 4” up or down drop-in landscape fixture has a corrosion resistant solid brass housing designed for outdoor applications. The included RGB + tunable white MR16 bulb has various color-changing and tunable white modes. Adjust speed, brightness, saturation, and bulb color with the remote or smart device using the Wi-Fi Hub. Bulb is equipped with a memory setting and will return to the selected mode prior to being powered off. To prevent water intrusion, the fixture is sealed with a weathertight silicone o-ring. The 12V down light is versatile and can be used as downlighting on deck posts or landscape lighting. Connect the down light to the existing 12V landscape system, or pair with a low-voltage transformer for a new system. Can be mounted for up or down lighting. Installation hardware is included.
Also available with a single-color MR16 bulb or as a fixture only.
Also available with a single-color MR16 bulb or as a fixture only.
Product Details:
- Control up to 8 light groups with RF remote or Tuya Smart App
- RF remote has a 100’ communication range
- Solid brass housing with a glass lens
- 25° beam angle
- IP54 waterproof rating
- Surface mount using the included hardware
- 12V AC/DC
- Lifetime Warranty
Applications:
- Decks
- Landscape Lighting
- RVs and Motorhomes
Super Bright LEDs, Inc. warrants that products carrying a lifetime warranty will be free from defects in the material and workmanship for the lifetime of the product. If Super Bright LEDs verifies that the defect was not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product with the same product. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
Specifications
Base Type | GU5.3 (MR16) |
---|---|
Beam Angle
Beam Angle
Beam angle is used to express the width of the light emitting from the source. The narrower the beam angle the more focused the light energy is. Comparing two 40 watt lights one with a beam angle of 30(a) and another with a beam angle of 90(b), They both produce the same amount of light output but (a) will appear brighter in the beam angle compared to (b) at the sacrifice of light spread.
![]() |
25° |
CCT
CCT
![]() |
2700K-6500K |
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
330 mA |
Dimmable | Yes |
Dimmer Type
Dimmer Type
|
Remote Controlled |
Equivalency | 35 Watt Halogen |
Finish | Bronze |
Hub Required | Optional |
Input Connection Type | Screw Terminals |
IP Rating
IP Rating
![]() |
IP54 |
LED Color | RGB+Tunable White |
Lumens | 280 Lumens |
Mount Type | Surface Mount |
Operating Voltage | 12V AC/DC |
Product Materials | Brass Housing, Glass Lens |
Warranty | Lifetime |
Wattage | 4 Watts |
Wire Gauge | 18 AWG |
Part NO | Supported Smart Phone Apps |
---|---|
WSR-LRR-RGBMR16-R-V | MiBoxer |
WSR-LRR-RGBMR16-V | MiBoxer, Smart Life by Tuya / Tuya Smart |
WSR-LRR-RGBMR16-W-V | MiBoxer |
