TCP QTL Series - 2' LED High Bay Fixture - 130W - 17,550 Lumens - 320W MH Equivalent - 5000K

TCP QTL Series - 2' LED High Bay Fixture - 130W - 17,550 Lumens - 320W MH Equivalent - 5000K

brand logo
Part Number
QHB2UZDE450K

Features

  • Durable, lightweight and easy-to-install construction
  • Equivalent to 320W MH fixture
  • Standard frosted lens for glare control
View more details
In Stock
$119.99 ea.
Free Shipping
On orders $300 and up within the contiguous U.S.
Read More

Item does not qualify

Overview

The QTL Series High Bay fixture features a lightweight extruded aluminum body and delivers 17,550 lumens resulting in a versatile solution for multiple applications. The included mounting hardware makes the QHB2UZDE450K High Bay easy to install and will provide a long-lasting, durable light source for commercial and industrial applications.

Product Details:

  • Steel housing with a frosted lens for reducing glare
  • Damp-location rated
  • 0-10V smooth dimming
  • Hanging kit included
  • 120-277 VAC
  • Certified by UL
  • DLC 5.1 Standard
  • 5-year warranty
DLC
DLC
Certified by UL
Certified by UL
5 Years
5 Years
80+ CRI
80+ CRI
0-10V Dimmable
0-10V Dimmable
IP20
IP20
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
This product has been certified by Underwriter Laboratories to their engineering and safety standards.
The DesignLights Consortium® (DLC®) partners with energy-efficiency groups and utility companies to establish a set of standards for commercial LED light fixtures. The product is tested and must meet quality, energy-efficiency, and performance requirements to be added to the DLC's Qualified Products List. For more information, click here. To view all of our DLC® listed products, click here
IP Ratings
luxiflux tool image

Incorporate this product in your next project by using our Lighting Layout Tool.

Try it now
Use as a guide only—values are based on our own in-house testing. Contact us for additional information or to discuss your lighting needs.

Specifications

Ambient Operating Temperature -20~+50 °C (-4~+122 °F)
Beam Angle 120°
Brand TCP
CCT Value 5000K
Certifications/Compliance Certified by UL, DLC
CRI 80+
Dimmable Yes
Dimming Type 0-10V
DLC Product ID PMEB8DS9
Efficacy 135 lm/W
Environmental Rating Non-weatherproof, Suitable for Damp Locations
Equivalency 320 Watt Metal-Halide
Finish White
Input Connection Type Pigtail
Intensity 17550 Lumens
IP Rating IP20
LED Color Cool White
Rated Life (L70) 50000 Hours
Length 24 in. (2 ft)
Lens Color Frosted
Lens Type Acrylic
Microwave Motion Sensor Optional
Operating Voltage 120-277 VAC
Power Consumption 130 Watts
Power Factor ≥0.9
Product Materials Acrylic Lens, Steel Housing
Product Weight 6.7 lb (3.0 kg)
UL File Number E328542
Warranty 5 Year
