TCP QTL Series - 2' LED High Bay Fixture - 130W - 17,550 Lumens - 320W MH Equivalent - 5000K
Part Number:
QHB2UZDE450K
Manufacturer Part Number:
$119.99
ea.
Was
In Stock
Features
- Durable, lightweight and easy-to-install construction
- Equivalent to 320W MH fixture
- Standard frosted lens for glare control
Related Products
Overview
The QTL Series High Bay fixture features a lightweight extruded aluminum body and delivers 17,550 lumens resulting in a versatile solution for multiple applications. The included mounting hardware makes the QHB2UZDE450K High Bay easy to install and will provide a long-lasting, durable light source for commercial and industrial applications.
Product Details:
- Steel housing with a frosted lens for reducing glare
- Damp-location rated
- 0-10V smooth dimming
- Hanging kit included
- 120-277 VAC
- Certified by UL
- DLC 5.1 Standard
- 5-year warranty
QHB2UZD Specification Sheet
QHB2UZDE450K IES File
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
The DesignLights Consortium® (DLC®) partners with energy-efficiency groups and utility companies to establish a set of standards for commercial LED light fixtures. The product is tested and must meet quality, energy-efficiency, and performance requirements to be added to the DLC's Qualified Products List. For more information, click here. To view all of our DLC® listed products, click here
This product has been certified by Underwriter Laboratories to their engineering and safety standards.
Need help?
Use our Lighting Layout Tool to see how this product illuminates your space.
Specifications
| Ambient Operating Temperature | -20 to 50 °C (-4 to 122 °F) |
|---|---|
| Beam Angle | 120° |
| Brand | TCP |
|
CCT
CCT
|
5000K |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
Certified by UL, DLC |
|
CRI
CRI
|
80+ |
| Dimmable | Yes |
|
Dimmer Type
Dimmer Type
|
0-10V |
| DLC Product ID | PMEB8DS9 |
| Efficacy | 135 lm/W |
|
Environmental Rating
Environmental Rating
|
Non-weatherproof, Suitable for Damp Locations |
| Equivalency | 320 Watt Metal Halide |
| Finish | White |
| Input Connection Type | Pigtail |
|
IP Rating
IP Rating
|
IP20 |
| LED Color | Cool White |
| Rated Life (L70) | 50000 Hours |
| Length | 24 in. (2 ft) |
| Lens Color | Frosted |
| Lens Type | Acrylic |
| Lumens | 17550 Lumens |
| Microwave Motion Sensor | Optional |
| Operating Voltage | 120-277 VAC |
| Power Factor | ≥0.9 |
| Product Materials | Acrylic Lens, Steel Housing |
| Product Weight | 6.7 lb (3.0 kg) |
| UL File Number | E328542 |
| Warranty | 5 Year |
| Wattage | 130 Watts |
