700mA Constant Current LED Driver

Constant Current LED Driver - 700mA - 3-12 VDC - 3W LED Driver - 3-12 VDC

Part Number
$8.99 ea.
In Stock
Free Shipping
On all orders $300 and up only within the U.S.
Read More.

Item does not qualify


CCD-700 constant current driver for powering high power LEDs. Input range of 100-240VAC - output range of 3~12VDC. Measures 40mm(1.57 in) x 20.4mm(0.80 in) x 58mm(2.28 in), case features built-in mounting tabs.
UL Recognized
UL Recognized
2 Years
2 Years
Super Bright LEDs, Inc. offers a 2-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Read More
In order for certain products within controlled categories, such as electrical and electronic devices, to be legally sold in the European Economic Area, they must bear a CE label, which stands for Conformité Européenne (European Conformity). Products with this label meet environmental, health, and safety standards put into place by European legislation.
Underwriters Laboratories (UL) LLC is an independent testing agency that works to verify product safety and quality. A UL-Recognized label ensures that a product component, such as a power supply or LED light strip, has been tested and verified as safe to use in a UL-Listed product. UL-Listed product samples are tested by UL and meet their Standards for Safety requirements.


Certifications/Compliance CE, Class 2, Class II, UL Recognized
Dimmable No
Environmental Rating Non-weatherproof, Suitable for Dry Locations
Input Connection Type Screw Terminals
Input Voltage 100-240 VAC
IP Rating IP20
Output Current 700 mA
Output Voltage 3-12 VDC
Warranty 2 Year
Print Specifications
Input AC Voltage Range(VAC) 100V~240VAC ± 6%
Frequency Range(Hz) 50 Hz / 60 Hz
AC Current 0.22A @ 115VAC / 0.085A @ 230VAC
Inrush Current
Leakage Current 1mA / 240VAC
Output DC Voltage(VDC) 3~12VDC
Rated Current Range(mA) 700mA ± 6%
Rated Power(W) 3~6W Max
Number of LEDs >5pcs
Efficiency(Typ.) 53%
Environment Ambient Temperature -10°C~+40°C Full Load
Operating Humidity 20% ~ 95% RH non-condensing
Storage Temperature / Humidity -20 ~ +80°C / 10% ~ 95% RH
Safety Approval Safety Standards UL, cUL Class 2
TUV / CE EN 61347 / EN55015
