Name: Little Dot SMD LED Accent Light - 30 Lumens - Warm White
Brand: Super Bright LEDs
SKU: LD1-WW
Price: 2.49 USD
Availability: InStock
Rating: 4.9 (157 reviews)

Overview

Description

with 10 different color options available the LD series Little Dot SMD LED Accent Light can create stunning visual features for cars, motorcycles, and RV’s. Designed with an ultra-compact housing that is less than ⅓ of an inch across allows this light to be mounted in small spaces using the 3M™ adhesive backing. Produces a wide 120° beam that spreads light across license plates, door handles, or hatches. Includes a 31” wire with a pigtail connection.

Note: The RGB version automatically cycles through colors and is not externally controllable.

Product Details:

Includes 31” pigtail connection
Rated IP65 for wet conditions
9-14.8 VDC
2 year warranty

Super Bright LEDs, Inc. offers a 2-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Read More

Applications

Boat Lights
Courtesy Light
Door Handle Lights
Trunk Lights
Motorcycle Accent Lighting
Marine Lighting

Specifications

Beam Angle	120°
Finish	Black
Input Connection Type	Pigtail
IP Rating	IP65
LED Lifetime	50000 Hours
LED Quantity	1 LED
LED Type	5050 SMD
Material	Plastic
Mount Type	Surface - Adhesive Backing
Operating Temperature	-30~+85 °C (-22~+185 °F)
Voltage	9-14.8 VDC
Wire Gauge	30 AWG
Wire Length	31in(78.7cm)

Print Specifications

Part NO	Brand	CCT Value CCT Value	Current Draw	LED Color	Lumen	Power Consumption
LD1-A	Super Bright LEDs		20 mA	Amber	5.5 Lumen	0.2 Watts
LD1-B	Super Bright LEDs		20 mA	Blue	5.3 Lumen	0.2 Watts
LD1-CW	Super Bright LEDs	6000K	20 mA	Cool 6000K	30 Lumen	0.2 Watts
LD1-G			20 mA	Green	10 Lumen	0.2 Watts
LD1-NW		4000K	20 mA	Natural 4000K	24 Lumen	0.2 Watts
LD1-P			20 mA	Pink	2.3 Lumen	0.2 Watts
LD1-R	Super Bright LEDs		20 mA	Red	6 Lumen	0.2 Watts
LD1-RGB			30 mA	RGB
LD1-UV			20 mA	UV (Blacklight)		0.2 Watts
LD1-WW	Super Bright LEDs	3000K	20 mA	Warm 3000K	25 Lumen	0.2 Watts

Accessories & Power Supplies

All Accessories

12V Power Supplies

Dimmers

Installation Supplies

Switches

Accessories Links

Accessory Category

Accessory Type:

$0.99 ea.

Mini ON/OFF Toggle Switch - Wired - Mini ON/OFF Toggle Switch - Wired Part Number: WRTS-SP-W
In stock

ON/OFF Single throw (SPST) Toggle Switch. Two 1/10in WIRED Male solder lug Contact Terminals 10A @ 12VDC. Mounting stem is 1/4in diameter and fits panels up to 1/8in thick.
$2.49 ea.

LED Indicator SPST Round Rocker Switch Part Number: RRS-SPx
In stock

ON/OFF Round Rocker Switch with LED indicator, three 3/16" male contact terminals with #6 screw contacts. Use SCFP-2218 3/16" female push-on connector. 15 Amp max at 12VDC. Mounting hole 13/16" in diameter and fits panels up to 1/8" thick.
