Mean Well LED Switching Power Supply - SP Series - Built-in PFC - 24 VDC - 100W / 150W / 200W / 320W
Part Number:
RSP-x-24
Manufacturer Part Number:
Starting at
$53.99
ea.
Starting at
Was
Features
- Built-in PFC
- Over Temperature Protection
- Enclosed Power Supply
- Indicator when Powered On
- Fixed Switching Frequency
- Over Voltage Protection
Related Products
Overview
The Mean Well LED switching power supply is a safe and economical choice for powering your LED lighting. It has integrated short circuit, overload, overvoltage, and over-temperature protection. Additionally, it has a constant current limiting circuit, a full load burn-in, and a fixed switching frequency. It can withstand a universal AC input range of 84-264VAC, and multiple wattage options make it a versatile and easy-to-use option for powering LED lighting systems.
Product Details:
- Universal AC input
- Built-in active PFC function
- High efficiency
- Cooling by free air convection
- LED indicator for power on
- Protections: Short circuit / Overload / Overvoltage / Over temperature
- 3-Year warranty
Documents
RSP User Manual
Super Bright LEDs, Inc. offers a 3-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
Underwriters Laboratories (UL) LLC is an independent testing agency that works to verify product safety and quality. A UL-Recognized label ensures that a product component, such as a power supply or LED light strip, has been tested and verified as safe to use in a UL-Listed product. UL-Listed product samples are tested by UL and meet their Standards for Safety requirements.
Specifications
| Brand | Mean Well |
|---|---|
| Built-in PFC Function | Yes |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact, energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else who may be involved confidence that the product is safe and will work well in their application. UL and ETL certifications relate to safety and installation and are the most common for power supplies. |
UL Recognized |
| Dimmable | No |
|
Dimming Control
Dimming Control
TRIAC Dimming: This is the most commonly recognized dimming type, with TRIAC Dimmers found in most Home Centers and hardware stores. TRIAC (TRIode for Alternating Current) dimmers operate by modifying the voltage waveform, reducing the amount of power input to the device being controlled. Reducing the input power will result in a corresponding reduction in a power supply's output voltage/current or a decrease in the lumen output of a light fixture. TRIAC dimmers come in two variations: Forward Phase and Reverse Phase
0-10V Dimming: This type of dimming control is most commonly found in commercial applications. It works by varying a voltage from 0 to 10 VDC on dedicated dimming wires. The output of a power supply or light fixture is proportional to the voltage applied. Pulse-Width Modulation (PWM) Dimming: This dimming control adjusts output by rapidly turning the output on and off at a fixed frequency. The proportion of on-time to total time sets the dimming percentage. Potentiometer Dimming: Potentiometer dimming varies the output using a variable resistor, or potentiometer, to set the dimming level. |
Non-Dimmable |
|
Environmental Rating
Environmental Rating
|
Non-weatherproof, Suitable for Dry Locations |
| Input Frequency Range | 47 - 63 Hz |
| Input Connection Type | Screw Terminals |
| Input Voltage | 100-240 VAC |
|
IP Rating
IP Rating
|
IP20 |
| Multi-Tap | Yes |
| Number of Outputs | 1 |
| Output Connection Type | Screw Terminals |
| Output Voltage | 24 VDC |
| Warranty | 3 Year |
| Part NO | Output Current |
Output Power
Output Power
A power supply's power consumption is measured in watts and refers to the maximum amount of power it is capable of delivering. For best results, choose a power supply that offers a minimum of 20% wattage overhead for your application. Wattage overhead ensures that your project will function correctly, extends the life of the power supply, and offers greater design flexibility by allowing for project expansion. |
|---|---|---|
| RSP-100-24 | 4200 mA | 100 Watts |
| RSP-100-24(POWERCORD) | 4200 mA | 100 Watts |
| RSP-150-24 | 6300 mA | 150 Watts |
| RSP-150-24(POWERCORD) | 6300 mA | 150 Watts |
| RSP-200-24 | 8400 mA | 200 Watts |
| RSP-200-24(POWERCORD) | 8400 mA | 200 Watts |
| RSP-320-24 | 12500 mA | 320 Watts |
| RSP-320-24(POWERCORD) | 12500 mA | 320 Watts |
