Name: Linear LED Light Bar Fixture - 360 Lumens - Blue - 35 inch
Brand: Super Bright LEDs
SKU: EGLB-B35
Price: 34.99 USD
Availability: InStock
Rating: 4.7 (42 reviews)

Overview

Description

LuxBar Linear LED Light Bars are an extremely versatile solution for both automotive and indoor lighting needs such as cabinet lighting, under-cabinet lighting, interior vehicle lighting, bookshelf lighting, police/emergency vehicle task lighting, footwell lights, and trunk/cargo lights. The aluminum fixtures are available in 18", 35", or 44" lengths, and the LED light bars deliver smooth, flawless illumination with out visible bulbs or hot spots. Each light bar fixture has powerful 3014 SMD LEDs that emit up to 360 lumens of natural white, cool white, red, green, or blue illumination. And with a CRI (color rendering index) of 84, light from this LED fixture will represent the true color of any object or surrounding. Each extruded aluminum light bar has screw mounting tabs on both ends and is equipped with a plug-and-play CPS connector. The non-weatherproof LED light bar fixture operates with in a 9-14.5 VDC range to match your car's electrical system.

Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Read More

Applications

LED Cabinet Lighting
Footwell
Trunk
Emergency Vehicle Lighting
Bookshelves
Interior Vehicle Lights
Cargo Lighting
Under-Cabinets
Display Cases
Trade Shows

Specifications

Ambient Operating Temperature	-20~+40 °C (-4~+104 °F)
Dimmable	Yes
Environmental Rating Learn more about environmental rating	Non-weatherproof
Finish	Black
LED Beam Angle Beam angle is used to express the width of the light emitting from the source. The narrower the beam angle the more focused the light energy is. Comparing two 40 watt lights one with a beam angle of 30(a) and another with a beam angle of 90(b), They both produce the same amount of light output but (a) will appear brighter in the beam angle compared to (b) at the sacrifice of light spread.	160°
LED Type	3014 SMD
Operating Voltage	9-14.5 VDC
Rated Life (L70)	50000 Hours
Strip Width	10mm (0.39in)
Wire Length	10in(25.4cm)

Print Specifications

Part NO	Brightness	Color Temperature Color Temperature Correlated Color Temperature is the hue, or tint of white to expect from a light source and is measured in kelvin. Lower numbers give off a warmer white that is closer to candle light, and is good for relaxed and cozy spaces. Higher numbers give off a cooler white light that will appear more blueish. While values to the middle of the spectrum give off a more neutral or natural white light that is similar to daylight. Natural and cool white are considered ideal for task lighting.	Current Draw Current Draw Current Draw is used to size fuses and wire for an electrical circuit. Current draw is the amount of energy consumed by an LED or LEDs in an electrical circuit at a specific voltage, measured in amps (A) or milliamps (mA).	Length	Power Consumption	Shipping Exclusions and Details Shipping Exclusions and Details Shipping exclusions apply to some products, making them ineligible for free shipping. Any order with a combined weight of over 150 pounds or containing an excluded item will be excluded from free shipping automatically. One or more exclusions may apply to the same product as well. Exclusions per item may include, but are not limited to, the following: • Any package with any two dimensions of the package over 30 inches. • Any package with a single side of the package over 42.3 inches. • Any package with a total combined length of the longest side added to 2 times the second and third longest sides over 130 inches. (L + 2H + 2W) • Any package with a weight over 50 pounds.	Wattage per Foot
EGLB-B18	16.7 lm/ft	Blue	300 mA	18in (1.5ft)	4 Watts	Excluded From Free Shipping	2.7 Watts
EGLB-B35	16.8 lm/ft	Blue	550 mA	35in (2ft 11in)	7 Watts		2.5 Watts
EGLB-B44	16 lm/ft	Blue	700 mA	44in (3ft 8in)	10 Watts	Excluded From Free Shipping	2.6 Watts
EGLB-G18	67 lm/ft	Green	300 mA	18in (1.5ft)	4 Watts		2.7 Watts
EGLB-G35	65 lm/ft	Green	550 mA	35in (2ft 11in)	7 Watts		2.5 Watts
EGLB-G44	65 lm/ft	Green	680 mA	44in (3ft 8in)	9 Watts	Excluded From Free Shipping	2.5 Watts
EGLB-R18	31 lm/ft	Red	270 mA	18in (1.5ft)	4 Watts		2.4 Watts
EGLB-R35	31 lm/ft	Red	510 mA	35in (2ft 11in)	7 Watts		2.4 Watts
EGLB-R44	30 lm/ft	Red	630 mA	44in (3ft 8in)	9 Watts	Excluded From Free Shipping	2.3 Watts

Accessories & Power Supplies

All Accessories

Installation Supplies

12V Power Supplies

Dimmers

Connectors

Controllers

Switches

Accessories Links

Accessory Category

Accessory Type:

$1.99 ea.

CPS-x2ST Standard Barrel Connector to Screw Terminal Adapter Part Number: CPS-x2ST
In stock

CPS-x2ST standard 5.5mm male or female barrel connector to screw terminal adapter. CPS-F2ST adapter allows products with pigtail power connections to be powered by CPS series power supplies.
$1.49 ea.

CPS-PT Pigtail CPS Power Adapter Cable - Pigtail Wire CPS-Cable Part Number: CPS-PT
In stock

Pigtail wire leads power adapter cable for compact power supplies. Allows products with power wires to connect with 5.5mm barrel connector. 63.5cm(25in) length.
$2.49 ea.

CPS-EXTx series Power Cable Extensions Part Number: CPS-EXTx
In stock

CPS-EXTx extension cable for CPS power supplies or BPS-12VDC-x battery power supplies with 5.5mm barrel connector. Available in 100cm(39.3in) or 300cm(118in) length and is for low voltage DC cables.
$4.49 ea.

CPS-MxF Compact Power Supply to Splitter Cable Part Number: CPS-MxF
In stock

1 female 5.5mm barrel connector to 2 or 4 male 5.5mm barrel connectors for our CPS series power supplies. Easily power multiple products with one Compact Power Supply. 52.07cm(20.5in) length.
$0.85 ea.

CPS series Male to Male Direct Barrel Connectors - Male to Male Part Number: CPS-M2M
In stock

Standard 5.5mm male to male direct connector for CPS series Compact Power supplies or BPS Battery Power supply. Can be used to extend lengths of power wires.

$29.99 ea.

Wireless Single Color LED Dimmer Switch for EZ Dimmer Controller - EZD-1C-WM Part Number: EZD-1C-WM
In stock

Designed for use with the Wireless LED 1-Channel EZ Dimmer Receiver or Wireless LED 4 Channel EZ Dimmer Receiver with Channel Pairing, this single-color wireless LED dimmer switch fits in standard wall switch boxes and provides on/off control as well as fixed levels of dimmability. The dimmer knob transmits an RF signal to the wireless receiver from up to 300' away in open air. The wall-mounted wireless dimmer includes 2 mounting screws and a required 3V CR2032 battery installed.
$14.99 ea.

Mini RF Single Color Push Button LED Dimmer Switch with Magnetic Base for EZ Dimmer Controller - EZD-1C-PB Part Number: EZD-1C-PB
In stock

Designed for use with the Wireless LED 1-Channel EZ Dimmer Receiver or Wireless LED 4 Channel EZ Dimmer Receiver with Channel Pairing Option, this push-button LED dimmer switch features a magnetic base and provides both standard on/off controls as well as the ability to dim and brighten LED light strips. The push-button dimmer transmits an RF signal to the wireless receiver from up to 300' away in open air. The wireless dimmer includes 2 mounting screws and a required 3V CR2032 battery installed.
