Discontinued
We have discontinued this product permanently. Please find suggested replacement products from below section.
MaxLite LED GEN 3 Linear High Bay - 270W - Control Ready - Selectable CCT - Up To 15,750 Lumens - 4000K / 5000K
Part Number:
HL3-270UF-CSCR
Manufacturer Part Number:
Discontinued
Features
- V-hook and 40" knotted chain included in standard model
- CCT Selectable, fixtures are set to 5000K as a default factory setting
- Controls Ready – can be paired with the new cMax controls nodes
- Suitable for damp locations
- DLC 5.1 Premium
Related Products
Overview
The HL3 LED Highbay Linear Series Gen 3 offers industry-leading efficacy (150lm/W), customizability with CCT select switch (4000K & 5000K), and scalability for high ceiling applications such as warehouses, distribution centers, manufacturing facilities, and big box retailers. This premium compact highbay covers a wide range of applications with 11,000 lumens at just 1.5 ft length up to 40,000 lumens at 4 ft length. The product has an integrated sensor port for easy in-field plug-and-play sensor installation. It is compatible with the Maxlite c-Max system (DLC NLC qualified), making it attractive for significant utility rebates. MaxLite's new Controls Ready (CR) fixtures allow for quick and easy in-field installation (plug-and-play) of controls. Purchase any CR fixture and the required Controls Node, and you're all set! See the accessory table for all control options available for this fixture.
Product Details:
- White steel housing and polycarbonate lens
- 0-10V dimming
- 120-277 VAC
- Certified by UL
- DLC 5.1 Premium
- 10-year standard warranty with labor allowance
Warranty Limitations: Product must be rated for application per the Product Data Sheet (PDS); operated ≤16 hrs; in ambient temperatures -4°F to 77°F. The product has a warranty of five years if ambient operating temperatures fall outside the -4°F to 77°F range. Up to $25/unit; registration is required. Additional coverage may be available for purchase; contact MaxLite. Excludes EM/MS versions; component warranty applies.
Documents
HL3-270UF-CS-4000K
HL3-270UF-CSCR Specification Sheet Applications:
- Big Box Retailers
- Convention Centers
- Distribution Centers
- Factories
- Gymnasiums
- High Bays
- Manufacturing Plants
- Packaging Facilities
- Warehouses
Super Bright LEDs, Inc. offers a 10-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
This product has been certified by Underwriter Laboratories to their engineering and safety standards.
This product meets higher lumen and efficacy standards than are required for a normal DLC® classification. This classification also requires submission of a driver IN-SITU temperature measurement test (ISTMT) along with information regarding integral controls.
Need help?
Use our Lighting Layout Tool to see how this product illuminates your space.
Specifications
| Ambient Operating Temperature | -20 to 50 °C (-4 to 122 °F) |
|---|---|
| Beam Angle | 110° |
| Brand | MaxLite |
|
CCT
CCT
|
4000K, 5000K, Selectable CCT |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
Certified by UL, DLC Premium |
|
CRI
CRI
|
80+ |
|
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
2.25 A @ 120 VAC, 975 mA @ 277 VAC |
| Dimmable | Yes |
| DLC Product ID | S-KW9IOQ |
| Efficacy | 150 lm/W |
|
Environmental Rating
Environmental Rating
|
Non-weatherproof, Suitable for Damp Locations |
| Equivalency | 1000 Watt Metal Halide |
| Finish | White |
| Input Connection Type | Pigtail |
| Integrated Surge Protection | 2.5 kV |
|
IP Rating
IP Rating
|
IP20 |
| LED Color | Warm White, Natural White, Cool White, Selectable CCT |
| Rated Life (L70) | 100000 Hours |
| Length | 48 in. (4 ft) |
| Lens Color | Frosted |
| Lens Type | Polycarbonate |
| Lumens | 40500 Lumens |
| Microwave Motion Sensor | Optional |
| Operating Voltage | 120-277 VAC |
| Power Factor | ≥0.9 |
| Product Materials | Polycarbonate Lens, Steel Housing |
| Product Weight | 16.8 lb (7.6 kg) |
| UL File Number | E361011 |
| Warranty | 10 Year |
| Wattage | 270 Watts |
