                            210W LED Linear High Bay - 28,350 Lumens - 400W MH Equivalent - 4000K / 5000K

210W LED Linear High Bay - 28,350 Lumens - 400W MH Equivalent - 4000K / 5000K

Part Number


  • Energy-efficient and low maintenance
  • High efficacy of 135 lm/W
  • Suspension mounting kit included
  • DLC 5.1 Premium
View more details

$139.99 ea.
In Stock
Only %1 left
Free Shipping
On orders $30 and up within the contiguous U.S.
Read More

Item does not qualify


The 2-foot LED linear high bay is an energy-efficient and low maintenance lighting solution for a wide range of commercial applications. The high bay delivers 28,350 lumens with a high 135lm/W output. The polycarbonate lens diffuses light, creating an even 110° beam angle. Install using the included suspension mounting kit or using the 1/2 “ knockouts. Ideal for commercial applications such as convention centers, gymnasiums, and manufacturing plants.
Product Details:
  • White steel housing and polycarbonate lens
  • IP20 rating for damp or dry locations only
  • Rated Lifetime: 80,000 hours
  • 0-10V Dimming
  • Link fixtures using the 1/2“ trade size knockouts
  • Certified by UL
  • DLC 5.1 Premium
  • 5-year warranty


  • Auditoriums
  • Cafeterias
  • Commercial Buildings
  • Distribution Centers
  • Grocery Stores
  • Gymnasiums
  • Manufacturing Plants
  • Retail Applications
  • Warehouses
DLC Premium
DLC Premium
Certified by UL
Certified by UL
5 Years
5 Years
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
This product has been certified by Underwriter Laboratories to their engineering and safety standards.
This product meets higher lumen and efficacy standards than are required for a normal DLC® classification. This classification also requires submission of a driver IN-SITU temperature measurement test (ISTMT) along with information regarding integral controls.
luxiflux tool image

Incorporate this product in your next project by using our Lighting Layout Tool.

Try it now
Use as a guide only—values are based on our own in-house testing. Contact us for additional information or to discuss your lighting needs.


Beam Angle 110°
Brand Super Bright LEDs
Comparable Wattage 400 Watt Metal-Halide
CRI 80+
Current Draw 1.8 A @ 120 VAC, 760 mA @ 277 VAC
Dimmable Yes
Dimming Type 0-10V
Efficacy 135 lm/W
Finish White
Input Connection Type Pigtail
IP Rating IP20
LED Lifetime 80000 Hours
Length 24in (2ft)
Lumen 28350 Lumens
Material Polycarbonate Lens, Steel Housing
Microwave Motion Sensor Optional
Operating Temperature -20~+50 °C (-4~+122 °F)
Power Consumption 210 Watts
Power Factor ≥0.9
Product Weight 12lb 10.4oz (5.74kg)
Standards And Certifications Certified by UL, DLC Premium
UL File Number E366643
Voltage 120-277 VAC
Warranty 5 Year
Wire Gauge 18 AWG
Print Specifications
Swipe left to see additional specifications
Part NO CCT Value LED Color
LHBDP3-40K210 4000K Natural 4000K
LHBDP3-50K210 5000K Cool 5000K
