Green Creative 63W HID LED Retrofit Bulb - Post Top Lamp - EX39 Base - Selectable Wattage - Up To 8,190 Lumens - 277V - 38W / 50W / 63W - 5000K
Part Number:
63HID-850-277V-EX39-RC
Manufacturer Part Number:
63HID/850/277V/EX39/RC
$67.99
ea.
Was
In Stock
Features
- Field adjustable wattage using integral rotary control
- 320° omnidirectional beam angle
- Equivalent to 175W-250W HID lamps
- Thermal protection against overheating
Related Products
Overview
The 63W HID Post Top Lamp from Green Creative is designed to replace HID lamps between 175-250W. Select the wattage of 63HID-850-277V-EX39-RC using the control at the top of the bulb, selecting between 38W, 50W, and 63W. An integrated thermal sensor reduces power to the lamp in the event the ambient temperature exceeds 122°F (50°C). The bulb also has an integral 6kV surge protector. Suitable for use in fully enclosed fixtures.
Product Details:
- White housing with a clear lens
- 320° omnidirectional beam angle
- EX39 base
- Type B Ballast Bypass
- 6kV Surge protection
- 120-277 VAC
- UL Listed & UL Classified
- DLC 5.1 Standard
- 5-year warranty
xHID Specification Sheet
63HID-850-277V-EX39-RC IES File Applications:
- Cobra Heads
- High Bays
- Low Bays
- Post Tops
- Retail Shops
- Shoeboxes
- Street Lights
- Wall Packs
- Warehouses
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
Underwriters Laboratories (UL) LLC is an independent testing agency that works to verify product safety and quality. A UL-Listed label means that product samples have been tested by UL and that the product meets their Standards for Safety requirements.
Underwriters Laboratories (UL) LLC is an independent testing agency that works to verify product safety and quality. UL tests specific properties of product samples to ensure that they adhere to applicable UL requirements, Standards for Safety, and other national and international organization's standards.
The DesignLights Consortium® (DLC®) partners with energy-efficiency groups and utility companies to establish a set of standards for commercial LED light fixtures. The product is tested and must meet quality, energy-efficiency, and performance requirements to be added to the DLC's Qualified Products List. For more information, click here. To view all of our DLC® listed products, click here
Need help?
Use our Lighting Layout Tool to see how this product illuminates your space.
Specifications
| Ambient Operating Temperature | -20 to 45 °C (-4 to 113 °F) |
|---|---|
| Ballast Compatibility | Type B (Ballast Bypass) |
| Base Type | EX39 (Mogul Base) |
| Beam Angle | 320° |
| Brand | Green Creative |
| Bulb Type | Corn Bulb |
|
CCT
CCT
|
5000K |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
DLC, UL Classified, UL Listed |
|
CRI
CRI
|
80+ |
|
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
137/181/227 mA @ 277 VAC, 317/417/525 mA @ 120 VAC |
| Dimmable | No |
| DLC Product ID | PLB5KMAWS9IR |
| Efficacy | 130 lm/W |
|
Environmental Rating
Environmental Rating
|
Non-weatherproof, Suitable for Damp Locations |
| Equivalency | 175 Watt Metal Halide, 250 Watt Metal Halide |
| Finish | White |
| Integrated Surge Protection | 6 kV |
|
IP Rating
IP Rating
|
IP20 |
| LED Color | Cool White |
| Rated Life (L70) | 50000 Hours |
| Lens Color | Clear |
| Lumens | 4940 Lumens, 6500 Lumens, 8190 Lumens |
| Manufacturer Part Number | 63HID/850/277V/EX39/RC |
| Operating Voltage | 120-277 VAC |
| Power Factor | ≥0.9 |
| Product Weight | 1.7 lb (0.8 kg) |
| UL File Number | E345134, E364641 |
| Warranty | 5 Year |
| Wattage | 38 Watts, 50 Watts, 63 Watts |
