TCP 24W LED Vapor Tight Light Fixture - 2' Industrial Light - 3,120 Lumens - 5000K
Part Number:
VTF2UZDA150K
Manufacturer Part Number:
$74.99
ea.
Was
Clearance
Features
- Vapor tight construction for commercial and industrial applications
- Durable plastic housing and frosted PC lens
- Wide 120° beam angle
- IP65 waterproof rating
Overview
The TCP 24W LED vapor tight light fixture features waterproof and durable construction. The steel housing and frosted PC lens protect the fixture in industrial facilities, commercial kitchens, and laundromats. The clips secure the lens to the housing, creating a waterproof seal against water and dust. The wide operating temperature of negative 4 degrees to 122 degrees Fahrenheit ensures the fixture can be safely installed in areas of extreme temps. Mounting hardware is included for quick and easy installation.
Product Details:
- White plastic housing and frosted polycarbonate lens
- IP65 waterproof rating
- 120° beam angle
- Surface mount
- 120-277 VAC
- Certified by UL
- DLC 5.1 Standard
- 5-year warranty
Documents
VTF Specification Sheet
VTF2UZDA150K IES File Applications:
- Conference Rooms
- Drop Ceilings
- Educational Facilities
- Hospitality
- Hospitals
- Linear Fluorescent Fixtures
- Offices
- Strip Fixtures
- Suspended Grid Ceilings
- Troffer Fixtures
- Wraparound Fixtures
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
The DesignLights Consortium® (DLC®) partners with energy-efficiency groups and utility companies to establish a set of standards for commercial LED light fixtures. The product is tested and must meet quality, energy-efficiency, and performance requirements to be added to the DLC's Qualified Products List. For more information, click here. To view all of our DLC® listed products, click here
This product has been certified by Underwriter Laboratories to their engineering and safety standards.
Need help?
Use our Lighting Layout Tool to see how this product illuminates your space.
Specifications
| Ambient Operating Temperature | -20 to 50 °C (-4 to 122 °F) |
|---|---|
| Beam Angle | 120° |
| Brand | TCP |
|
CCT
CCT
|
5000K |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
Certified by UL, DLC |
|
CRI
CRI
|
80+ |
|
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
200 mA @ 120 VAC, 87 mA @ 277 VAC |
| Dimensions | 2ft |
| Dimmable | Yes |
|
Dimmer Type
Dimmer Type
|
0-10V |
| DLC Product ID | S-K2C4AT |
| Efficacy | 130 lm/W |
|
Environmental Rating
Environmental Rating
|
Suitable for Wet Locations, Waterproof |
| Equivalency | 2-lamp 17W T8 Tubes |
| Finish | White |
| Input Connection Type | Pigtail |
|
IP Rating
IP Rating
|
IP65 |
| LED Color | Cool White |
| Rated Life (L70) | 50000 Hours |
| Length | 24 in. (2 ft) |
| Lens Color | Frosted |
| Lens Type | Polycarbonate |
| Linkable | No |
| Lumens | 3120 Lumens |
| Microwave Motion Sensor | None |
| Operating Voltage | 120-277 VAC |
| Power Factor | ≥0.9 |
| Product Materials | Polycarbonate Lens, Steel Housing |
| Product Weight | 2.6 lb (1.2 kg) |
| UL File Number | E328542 |
| Warranty | 5 Year |
| Wattage | 24 Watts |
