20W Mini-Aux 4" Dual LED Off Road Work Light
- Select options to see various notes.
|50 - 99 pieces||$44.95 each|
|100 - 499 pieces||$39.96 each|
|500 - 999 pieces||$37.46 each|
|1000 + pieces||$34.97 each|
|For discount information or inquiring about larger quantity pricing, click here|
20 Watt Dual LED Mini Auxiliary Work Light features a compact low profile and unique modular design, which allows the user to assemble multiple lights into various configurations. 2 x 10 Watt CREE XM-L T6 LEDs. 9~32VDC operating voltage range, IP67 waterproof light. Black painted aluminum housing with clear lens. Available with narrow spot 15 degree. Can be mounted individually or combined with included hardware. Ideal for demanding work environments, including material handling, agricultural machinery, marine, mining, off-road trucks and equipment. 6" wire lead.
RoHS stands for Restriction of Hazardous Substances. Certain materials used in electronics and electrical products have been deemed hazardous to people and the environment and, therefore, must be limited. For a product to be RoHS compliant, testing must be performed and documented to show limited or no use of cadmium, hexavalent chromium, lead, mercury, polybrominated biphenyls, and polybrominated diphenyl ethers.
20W Mini-Aux 4" Dual Row LED
Off-Road Work Light
- Material handling
- Agricultural machinery lighting
- Marine LED lighting
- Mining LED lights for non-hazardous locations
- Vehicle Auxiliary Lamps
- Off-road equipment lighting
- Marine LED Lighting
- UTV / ATV Auxiliary Lights
Powered by 2 x 10 Watt CREE LED
1500 Raw Lumen of Cool White Light
Choose 15° Light Dispersion
Wide Operating Voltage Range From 9~50V DC
Water and Dust Proof Housing
Heavy-Duty Die Cast Aluminum Housing
Connect to Create unique Configurations
Durable Lens Stands Up to the Hardest Environments
120° Adjustable 304 Stainless Steel Mounting Bracket
IP (Ingress Protection) Rating
|Amps||1.02A||Beam Angle||15 degree|
|Beam Pattern||Spot||Bracket Thickness||1.50mm|
|Color Temperature||6000 K||Connector Type||Pigtail|
|Current Draw||1020mA||Efficacy||124 lm/w|
|Water Resistance||Waterproof IP67||LED Color||Cool White|
|LED Quantity||2 LEDs||LED Type||Cree XM-L T6|
|Length (in)||4.0in (0.33ft)||Raw Lumen||1500 Lumen|
|Mounting Bolt Dimensions||5.60mm x 19.20mm||Polarity Sensitive||Yes|
|Special Features||Waterproof||Standards And Certifications||RoHS Compliant|
|Power Consumption||13.8 Watts||Type||Fixture|
|Operating Voltage||9~32 VDC||Wattage||20 Watts|
Package Dimensions: 4.5" (11cm) x 3.35" (9cm) x 3.35" (9cm)
Package Weight: 1lb 0.80oz (0.48kg)
All specifications are subject to change without notice.
Lumen is a unit of measurement for the total amount of visible light emitted from a light source. It takes into account the varying sensitivity of the human eye to different wavelengths of light. Read more...
|Beam Angle||15 degree|
|Color Temperature||6000 K|
|Water Resistance||Waterproof IP67|
|LED Color||Cool White|
|LED Quantity||2 LEDs|
|LED Type||Cree XM-L T6|
|Length (in)||4.0in (0.33ft)|
|Raw Lumen||1500 Lumen|
|Mounting Bolt Dimensions||5.60mm x 19.20mm|
|Standards And Certifications||RoHS Compliant|
|Power Consumption||13.8 Watts|
|Operating Voltage||9~32 VDC|
Dimensions: 4.5" (11cm) x 3.35" (9cm) x 3.35" (9cm)
All specifications are subject to change without notice.
2. Lumen is a unit of measurement for the total amount of visible light emitted from a light source. It takes into account the varying sensitivity of the human eye to different wavelengths of light. Read more...
Tell Us What You Think
Share your own experience and photos of this product. Doing so will help inform other potential buyers and allow us improve our product lines. It may take up to 72 hours for your review to appear.
Astoundingly bright and well made , W/ low draw.
I bought a pair of these a little more than a month ago with (if they were bright enough and really 'reached out') the intention of using one one my S-10 pick-up and the other on one of my motorcycles directly under the headlight as "conspicuity lights". I mounted the one for my truck in an existing hole in the front bumper above the license plate and got it wired up with an "add a circuit" kit from a local parts store. I live in a very rural area and it's designated as "Open Range" so that any wildlife such as pigs, deer or an occasional roaming steer would be really hard to see until you hit them. After I got it working I had to aim it fairly low so as to not blind oncoming drivers but I'm amazed that even at the present angle it does very brightly illuminate the upcoming traffic signs and markers as far as 2000' and if both my headlights conked out, this little unit would be more than enough to get me safely home. I can hardly wait to start on my bike. I've seen other such LED lights for motorcycles that run as much as $750.00 for a pair that don't have much more output than a pair of these (1800 lmn vs.1500 lmn) and these only draw 995 milliamps each. I'm a repeat customer of SuperBrightLEDS and the prices and shipping are excellent as always. You won't be disappointed.
I bought a pair of these to also use with the 120 watt light bar on my truck. Their beam patter is tighter and I use them with the low beams. After a week one light failed and half of the light went dark. Called the service department and they sent out a replacement that arrived in Colorado in two days. Great service. Prepaid shipper for the return unit. I was dully impressed by their service.
A lot of light for the money
I was looking for a light to augment the highbeam on my motorcycle. This little light didn't disappoint at all! The allen screws which secure the mounting shoes were a little snug but thats no big deal. What isn't mentioned is that you can lock two or more of these together with the supplied hardware. There isn't a supplied connector, just bare ends for the power lead but since I plan on hard wiring this in its no big deal. Now that I've seen the output in person I plan on ordering a few more of these!
Great little lights
Just installed two of these in the open area on the grille of my 2011 F-150. Solid construction, well-made mounts. I highly suggest buying the wiring kit to go with it. The lights are perfect for adding additional illumination both down the road and to the sides. I bought them to better see deer when driving country roads, and they're perfect for that. Would recommend them to anyone.
Nice and small
Bought this for my Harley crash bars. Beam not as deep as the 3.25 spot. Still a great led light. Will use on my sport touting bike fork mounted. Has a wide pattern . Yes.. I recommend it.
Pair for snowmobile
I purchased these lights to use on a Yamaha Nytro snowmobile as I do a lot of riding at night in deer country. The Stock OEM lights simply to not have a wide enough beam to see deer off to the sides as you are riding. My goal with these lights were to set them up as long range headlights, but turned out for a wider field of view. Overall, easy to install, great low amp draw and overall pretty happy. I was a little dissappointed that the "reach" was not out as far as the stock incadencent light, but then again, these are pretty darn small. If they had the reach, they would have been a 5/5, but knocking it down to a 4/5.
