450W High Voltage LED Parking Lot Light - 1,500W MH Equivalent - 65,250 Lumens - 5000K - Type III-M Distribution - Optional Photocell
Part Number:
PLLD4-450W-277V-5000K-MTx
Manufacturer Part Number:
Starting at
$419.99
ea.
Starting at
Was
In Stock
Features
- Type III-M Light distribution
- Increase energy savings with optional photocell
- Multiple mounts available
- High Voltage 277-480 VAC
- DLC 5.1 Premium
See our full selection ofPLLD4 series parking lot lights.
Related Products
Overview
The 450W high voltage LED parking lot light is designed to provide extensive, reliable illumination for large open areas, such as parking lots, campuses, and parks. Featuring a Type III-M distribution pattern, this light ensures broad coverage, making it ideal for expansive spaces. The fixture is constructed with a heavy-duty bronze die-cast aluminum housing and a durable polycarbonate lens, offering robust protection against harsh outdoor conditions. By replacing traditional 1,500W metal halide fixtures with this low-maintenance LED light, you can significantly reduce energy consumption and maintenance costs. The light is available with or without a photocell, which requires installation. For dusk-to-dawn operation, select between a 277 VAC photocell or a 480 VAC photocell. With an IP65 waterproof rating and DLC 5.1 Premium certification, this fixture is both durable and energy-efficient, qualifying it for utility rebate programs.
Product Details:
- Photocell requires installation
- Bronze aluminum housing with a polycarbonate lens
- IP65 waterproof rating
- For dusk-to-dawn operation select between a 277 VAC photocell or a 488 VAC photocell
- DLC 5.1 Premium
- 5-year warranty
Documents
PLLD4 User Manual
PLLD4-50K450W-xLT3BR1 IES File Applications:
- Area Lighting
- Arenas
- Campus Lighting
- Car Dealerships
- Parking Lots
- Parks
- Roadways
- Sports Complexes
- Stadiums
- Street Lights
- Warehouses
Super Bright LEDs, Inc. offers a 5-year warranty to protect against manufacturer defects and malfunctions. If you experience failure of an LED or other component not caused by negligence, abuse, unauthorized repair or disassembly, we will replace the product within the warranty period. In the case the exact product is no longer available, a gift card for the value of the original purchase price will be provided. Super Bright LEDs administers all warranty claims in-house. Read More
This product meets higher lumen and efficacy standards than are required for a normal DLC® classification. This classification also requires submission of a driver IN-SITU temperature measurement test (ISTMT) along with information regarding integral controls.
This product has been certified by Underwriter Laboratories to their engineering and safety standards.
Need help?
Use our Lighting Layout Tool to see how this product illuminates your space.
Specifications
| Ambient Operating Temperature | -35 to 50 °C (-31 to 122 °F) |
|---|---|
| Brand | Super Bright LEDs |
| BUG Rating | B5-U0-G5 |
|
CCT
CCT
 |
5000K |
|
Certifications/Compliance
Certifications/Compliance
Standards and certifications comprise a vast number of companies and compliances that serve specific purposes—primarily addressing safety, environmental impact and energy efficiency, and sanitation. They are divided into categories for each product type and certification type to allow for very specific qualifications related to each product. When this system is being used as intended, it gives consumers, installers, suppliers, and anyone else that may be involved confidence that the product is safe and will work well in their application. The most common UL and ETL certifications relate to safety and installation, although they do also provide some sanitation-related certifications (using NSF standards). Another common certification body is the DLC, which specializes in certifying the performance of a light—mainly related to environmental impact and electrical efficiency. Learn more about different certification types here . |
Certified by UL, DLC Premium |
|
Current Draw
Current Draw
Current draw is calculated using the following formula: W/V = A, where W = the amount of power your light needs (wattage), V is the electrical system voltage (e.g., 120V AC), and A = amps. An ampere or amp (A) is the standard unit for electrical current. A milliamp (mA) equals one-thousandth of an amp, or 1000 mA is equivalent to 1 A.
Choosing LED fixtures with the correct amperage ensures safe and proper operation, preventing damage or injury. We recommend having all electrical components and fixtures installed by a certified professional electrician or lighting technician in compliance with all relevant standards and regulations. |
1.6 A @ 277 VAC, 940 mA @ 480 VAC |
| Dimmable | Yes |
|
Dimmer Type
Dimmer Type
|
0-10V |
|
Distribution Type
Distribution Type
|
Type III-M |
| DLC Product ID | S-OJMP26 |
| Efficacy | 145 lm/W |
|
Environmental Rating
Environmental Rating
 |
Suitable for Wet Locations, Waterproof |
|
EPA Rated
EPA Rated
The Effective Projected Area (EPA) refers to the strength of wind velocity a pole-mounted light fixture can withstand. EPA ratings are employed to assess whether lighting fixtures can adhere to the standards required by specific geographical regions. The Effective Projected Area is a measure used to determine the wind forces a lighting fixture might face.
For more information on calculating EPA and why it is important visit our blog 'What Is EPA and Why Do You Need To Know?' |
2.8 ft² |
| Equivalency | 1500 Watt Metal Halide |
| Finish | Bronze |
| Input Connection Type | Pigtail |
| Integrated Surge Protection | 10 kV |
|
IP Rating
IP Rating
 |
IP65 |
| LED Color | Cool White |
| Rated Life (L70) | 50000 Hours |
| Lens Type | Polycarbonate |
| Lumens | 65250 Lumens |
| Operating Voltage | 277-480 VAC |
| Power Factor | ≥0.9 |
| Product Materials | Aluminum Housing, Polycarbonate Lens |
| UL File Number | E366643 |
| Warranty | 5 Year |
| Wattage | 450 Watts |
| Wire Gauge | 18 AWG (L/N/G), 22 AWG (dimming) |
| Part NO | Mount Type |
Photocell
Photocell
What is a Photocell and How Does It Work?When an LED light is equipped with a photocell, the light will turn on and off automatically based on the available ambient light. Their unique functionality makes them ideal for outdoor area lighting specifically.Photocells are variable resistors that change the resistance in an electrical circuit depending on the amount of light present where they are mounted. Because of this, they must be mounted in exposed areas where they receive adequate light to function. Photocells, or photocontrols, come in a variety of shapes and sizes and can be integrated into a luminaire or be an added accessory depending on the light. Can a Photocell Be Bypassed?Some lights allow for a photocell to be bypassed as needed. When the photocell is bypassed, it allows for the luminaire to remain on constantly or be controlled by an existing switch or timer. Depending on the type of photocell and how it is installed in the fixture, it may be bypassable using a shorting cap, a slide or DIP switch, or by unplugging the photocell. Consult the user’s manual of the light to confirm which option(s) may be applicable and how to implement them safely. Always use caution and turn off supply power before working on wiring of any type.Shorting CapPhotocells on many commercial applications like parking lot and area lighting applications are mounted externally with a twist-lock socket or adapter. Swapping this for a shorting cap simply closes the circuit on your LED light fixture, which keeps your light in an always-on state. This allows it to be controlled externally as well if a central photocell or switch system is being utilized.DIP Switch or Slide SwitchWhile DIP switches and standard slide switches function differently in most cases, when integrated into the photocontrol system of a light they perform the same function. Switches like these are common on canopy and dusk-to-dawn barn lights. These types of switches allow you to toggle the photocell sensor on or off to fit your needs without any rewiring or replacing parts.Disconnect the WiringSome photocell designs, such as those commonly found in wall packs, allow the operator to simply unplug the photocell to allow the light to work in an always-on state or be controlled by an external switch. |
Product Weight |
|---|---|---|---|
| PLLD4-50K450W-BLT3BR1 | No Photocell | 19.7 lb (8.9 kg) | |
| PLLD4-50K450W-BLT3BR1-APM | Adjustable Arm Mount | No Photocell | 23.6 lb (10.7 kg) |
| PLLD4-50K450W-BLT3BR1-APM-JL | Adjustable Arm Mount | 277 VAC Photocell | 24.1 lb (10.9 kg) |
| PLLD4-50K450W-BLT3BR1-APM-JL-480 | Adjustable Arm Mount | 480 VAC Photocell | 24.1 lb (10.9 kg) |
| PLLD4-50K450W-BLT3BR1-FB2 | Yoke Bracket | No Photocell | 21.8 lb (9.9 kg) |
| PLLD4-50K450W-BLT3BR1-FB2-JL | Yoke Bracket | 277 VAC Photocell | 22.2 lb (10.1 kg) |
| PLLD4-50K450W-BLT3BR1-FB2-JL-480 | Yoke Bracket | 480 VAC Photocell | 22.3 lb (10.1 kg) |
| PLLD4-50K450W-BLT3BR1-JL | 277 VAC Photocell | 20.2 lb (9.2 kg) | |
| PLLD4-50K450W-BLT3BR1-JL-480 | 480 VAC Photocell | 20.2 lb (9.2 kg) | |
| PLLD4-50K450W-BLT3BR1-SF | Knuckle Slipfitter Mount | No Photocell | 22.8 lb (10.3 kg) |
| PLLD4-50K450W-BLT3BR1-SF-JL | Knuckle Slipfitter Mount | 277 VAC Photocell | 23.3 lb (10.6 kg) |
| PLLD4-50K450W-BLT3BR1-SF-JL-480 | Knuckle Slipfitter Mount | 480 VAC Photocell | 23.3 lb (10.6 kg) |
| PLLD4-50K450W-BLT3BR1-WM | Trunnion Mount | No Photocell | 22.9 lb (10.4 kg) |
| PLLD4-50K450W-BLT3BR1-WM-JL | Trunnion Mount | 277 VAC Photocell | 23.3 lb (10.6 kg) |
| PLLD4-50K450W-BLT3BR1-WM-JL-480 | Trunnion Mount | 480 VAC Photocell | 23.4 lb (10.6 kg) |
